Available M/E Layers
5 M/E
Effect Types
1 x DVE, Graphic, Transition, Chroma Key, Alpha Key, Luma Key
Downstream Keys
1 x Chroma, DVE
2 x Luma
Audio Mixing
2-Channel Mixing
Processing
Switching Type
Pushbutton
Input
Number of Video Input Sources
4
Video Inputs
4 x HDMI Female
Input Video Format
HDMI (10-Bit 4:2:2 YUV)
1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i 50/59.94/60 fps
720p 50/59.94/60 fps
Audio Inputs
2 x 1/8" / 3.5 mm TRS Stereo Analog Female
Embedded Audio Input
HDMI: 2-Channel (per Input)
Output
Video Output Channels
1
Video Outputs
1 x HDMI
Output Video Format
HDMI / RJ45 (10-Bit 4:2:2 YUV)
Embedded Audio Output
HDMI: 2-Channel (per Output)
Multiview Output
Yes
Monitor Output
Connectivity
Other I/O
1 x RJ45 LAN, Sync, Tally, Timecode, Firmware, Control Input/Output
1 x USB-C Firmware, Control Input/Output
Hardware
OS Compatibility
macOS 10.14 or Later
Windows 10
*As of April, 2020: Check with manufacturer for the most up-to-date compatibility
Wi-Fi
None
Bluetooth
Power I/O
1 x Barrel (12 VDC) Input
Power Consumption
36 W
Environmental
Operating Temperature
41 to 104°F / 5 to 40°C
Storage Temperature
14 to 140°F / -10 to 60°C
Operating Humidity
0 to 90%
General
Dimensions
9.35 x 4.07 x 1.38" / 23.75 x 10.34 x 3.51 cm
Weight
19.4 oz / 550 g
